Security Center

Network protocols: ONVIF, RTSP, SLINK, I9, GB28181 (optional)
Mobile viewing: Supports viewing on Apple and Android phones
Display mode: Supports access to 196 cameras (12MP/D1+64 preview+16 playback)
Intelligent detection: target counting, item detection, electronic fence, cross-border detection, reverse detection, departure detection, etc
Video input bandwidth: 640Mbps
Video compression: Smart265/H.265/H.264
Video resolution: 4K/5MP/3MP/1080P/720P/D1
Audio compression: G.711A
Audio input: IPC composite audio input
Video recording method: manual/external alarm/motion detection/timed/intelligent analysis alarm
Hard disk backup: Supports Raid 0/1/5/6/10
Playback capability: Supports synchronous playback of 4 * 4K/9 * 3MP/16 * 1080P video recordings
Playback modes: regular playback, event playback, external file playback
Storage interface: 48 SATA
Hard drive capacity: Maximum 16T per individual hard drive
Video storage path: local hard drive
Backup methods: USB flash drive, network backup
Network interface: 2 RJ45 1000M Ethernet ports
Serial interface: 1 standard RS-485 serial interface
2 USB ports, 1 USB 3.0
General
Power supply: ATX110-220V 300W 50-60Hz/N+1/N+2/3
Rated power consumption: ≤ 240W/N+1/N+2/3
Working environment: -10 ° C~55 ° C/10% -90%
Size: Equipment: 431.5mm × 600mm × 177.5mm
Weight: Net weight: 21Kg; Gross weight: 22Kg (without hard drive)
Packaging: 1 unit/box 748mmX575mmX300mm; Weight: 22 kilograms
